Level:
Entry to Mid Range RAID Solution
This
system was designed to provide a specific solution to
a client requirement. New systems would be conceptually
identical but with the addition of newer revisions of
hardware/firmware, more robust cabinets, and/or additional
comms or management features. Best of breed combinations
are always utilised.
Ideal
for desktop storage to mid-level enterprise storage
applications including audio, broadcast, prepress, compact
servers, high-speed backup and data serving. An internally
embedded Chaparral 3rd generation G -Series Ultra160
SCSI RAID controller (model G6322) provided support
for redundant data configurations and high data throughput
for maximum system uptime.
This
model accommodated up to ten 3.5" half-height or full-height
SCA LVD SCSI hard drives (10k and 15k rpm supported)
per shelf at up to Ultra160 SCSI speeds. Maximum number
of drives is 45. The enclosure is available as a tower
unit or a 19" rack configuration. includes daisy
chain ports, two hot-swap blowers, two hot-swap power
supplies, and six hot-swap drive canisters to support
always-online data availability.
|
|
|
- 10
Hot Swappable Drive Bays per shelf
- Host-independent
Ultra160 LVD subsystem
- 160MB/s
transfer rates
- No
single point of failure
- Massive
increase in data storage capacities
- Modular,
expandable tower and rack configurations
- Host
Independent
- More
than 15,000 IOPS
- Scalable
to 3.2 Terabytes
|
| Ideal
for the fault tolerant mission critical environments,
with the capability of sustaining over 180MB/sec sequential
RAID-5 reads from a single controller. The solution is
host independent and in conjunction with Seagate's 73GB
10,000rpm Ultra160 drives, offers scalability to over
3.2 Terabytes of storage per controller. The G6322 controller
can handle in excess of 15,000 IOPS making it extremely
fast in OLTP and multimedia rich applications. |
|
| Hard
Drive Options: |
- 9GB
10,000rpm
- 18GB
7,200rpm
- 18GB
10,000rpm
- 18GB
15,000rpm
- 36GB
7,200rpm
- 36GB
10,000rpm
- 73GB
10,000rpm
- 181GB
7,200rpm
|
|
|
Key
Specifications:
- Internally
embedded Chaparral G6322 RAID controller supports
RAID levels 0,1,0/1,4,3,5, and JBOD
- Chaparral
G5312 is powered by a 133 MHz AMD 5x86 processor and
supports up to 128MB of cache memory
- RS-232
port provides out-of-band monitoring and set-up of
RAID configuration
- Industry
standard hard drive interconnect, Single Connector
Attachment (SCA-2)
- Hot-swap
drive bays
- SCSI
LVD Ultra160, 160MB/sec maximum transfer rate supported
- Cable-less
design; multi-layer backplane for high signal integrity
- Dual
hot-swap blowers provide cooling to support 10k and
15k rpm drives
-
Dual hot-swap, auto-ranging power supplies
- Dual
SCSI channels
- Visual
and audible fault indicators for temperature, power,
or blower fault
- Operating
system independent
|
Ultra160
SCSI RAID
Ideal
for desktop storage to mid-level enterprise storage
applications
•
audio
• broadcast
• pre-press
• compact servers
• high-speed backup
• data serving
|
| |
|
|
|
For
more detailed technical specifications, ordering, and pricing
information,
please contact us at Discovery.
|
|
